Start with the parent alloy, not the rod that looks closest on a shelf. By verifying the base metal, service conditions, joint geometry and AWS classification, you can choose a filler that survives dilution, heat treatment, corrosion and the finished joint’s mechanical demands.
Key takeaways
- Confirm the base alloy and heat traceability before selecting a TIG filler rod.
- Use matching filler for compatibility, or dissimilar filler for defined service and joining needs.
- Account for dilution, joint geometry and rod diameter before setting the welding procedure.
- Record the filler classification, diameter, shielding gas and welding parameters in the specification.
Identify the Parent Alloy Before Choosing a Filler
A TIG rod cannot be selected reliably until you know the parent alloy, not merely its colour or surface appearance. Confirm the grade on each component, preserve traceability to the heat, and check whether the material has been repaired, plated or mixed with another alloy.
- Request the material certificate and match its grade, specification, thickness and heat number to the part.
- Read the material marking stamped, etched or tagged on the component. Record the grade and heat number before cutting or cleaning it away.
- If the certificate or marking is missing, use a PMI test. Portable XRF identifies many alloying elements but does not measure carbon; use optical-emission spectrometry when carbon content separates grades such as 304 from 304L or 316 from 316L.
- Test both sides of a dissimilar joint. Do not assume a stainless fitting, carbon-steel pipe or nickel overlay from its appearance.
| Evidence | What to verify | Consequence of a mismatch |
|---|---|---|
| Material certificate | Grade, specification and heat number | Stop selection until traceability is resolved |
| Heat number | Marking on the part matches the certificate | Treat the part as unidentified if numbers conflict |
| Material marking | Alloy designation and product form | Check whether the marking belongs to the actual component |
| PMI test | Element profile and test method | Use OES when carbon or light elements affect the grade |
| Unidentified metal | Confirmed chemistry from testing | Do not use a generic “stainless” or “aluminium” rod |
For nickel alloys and high-alloy corrosion-resistant materials, record the exact grade and service environment. ERNiCrMo-3 and ERNiCrMo-4 are not interchangeable by label alone; confirm the pairing against the qualified welding procedure or alloy manufacturer’s recommendation.
Match Filler Chemistry to the Base Metal and Service
ER70S-2 suits clean carbon steel and low-alloy steel when high-purity material is prepared carefully; its titanium, zirconium and aluminium deoxidizers tolerate small amounts of oxide. ER70S-6, also a 70-ksi-class filler, contains more silicon and manganese, producing a more fluid, wetting bead with greater tolerance of mill scale.
The “-2” and “-6” identify chemistry requirements, not strength grades.
| Base metal | Common TIG filler | Selection point |
|---|---|---|
| Carbon steel | ER70S-2 or ER70S-6 | Choose ER70S-2 for clean material; choose ER70S-6 for better wetting after thorough cleaning. |
| Low-alloy steel | Matching low-alloy classification | Match strength, toughness and any post-weld heat-treatment requirement. |
| 304 and 316 stainless steel grades | ER308L and ER316L | Use the matching grade for corrosion service; low carbon limits sensitisation, but 321 or 347 is better for sustained elevated temperature. |
| Nickel alloys | ERNiCrMo-3 | Match the nickel alloy family and corrosion environment, not merely tensile strength. |
| Aluminium | ER4043 or ER5356 | Check alloy, temper, crack sensitivity, anodising, colour and operating temperature before choosing. |
| Copper or brass | ERCu-family filler | Confirm conductivity, zinc loss and galvanic compatibility. |
| Titanium | ERTi-2 | Match grade, shielding quality and contamination control. |
Service requirements override a nominal match when corrosion, cryogenic toughness, elevated temperature, wear resistance or galvanic compatibility controls failure. Dilution can change deposited chemistry, and post-weld heat treatment can alter strength or corrosion resistance, so a matching rod is not automatically an acceptable weld metal.
Read AWS Classifications and Decide Between Matching and Dissimilar Fillers
AWS A5.18 classifications turn a TIG rod into a usable specification. In ER70S-2, “ER” identifies an electrode or rod, “70” indicates nominal 70-ksi tensile-strength weld metal, and “S” means solid wire.
The “-2” is a chemical-composition designation, not a lower strength grade; ER70S-6 is also nominally 70-ksi class, but its deoxidizer balance gives different weld-pool behaviour and greater tolerance of surface oxides.
| Classification | What the code tells you | Practical TIG use |
|---|---|---|
| ER70S-2 | Carbon-steel solid rod with a specified deoxidizer balance | Clean carbon or low-alloy steel where controlled chemistry matters |
| ER70S-6 | Carbon-steel solid rod with a different deoxidizer balance | Carbon steel with minor mill scale or less-than-perfect surface cleanliness |
| ER308L | Low-carbon chromium-nickel stainless filler | 304 stainless and compatible austenitic stainless joints |
| ER316L | Low-carbon, molybdenum-bearing stainless filler | 316 stainless where chloride corrosion resistance matters |
A matching rod is not automatically the safest choice. Dilution, service temperature, post-weld heat treatment and corrosion exposure can make a nominal match fail after welding.
Choose a dissimilar filler when it produces a more tolerant weld-metal composition. ER309L is commonly selected for carbon-steel-to-stainless joints because its chemistry accommodates dilution better than a direct stainless match. For nickel alloys, do not substitute by appearance: ERNiCrMo-3 and ERNiCrMo-4 differ materially, so follow the qualified procedure and alloy manufacturer’s recommendation.
Account for Dilution, Joint Design and Rod Diameter
A tight root opening or narrow groove needs a smaller TIG rod; a large rod can chill the pool and cause lack of fusion. A wide groove or large root gap needs more deposited metal, so a larger diameter improves deposition rate without repeated, erratic additions.
- For a deep, narrow joint, use a small rod and enough current to achieve root penetration. Do not raise rod diameter to compensate for inadequate penetration; correct the current, arc length and joint preparation.
- In vertical-up or overhead welding, choose a diameter that lets you control the smaller molten pool. Excessively large filler creates sagging, while an undersized rod disappears quickly and forces frequent additions.
- Specify rod diameter and current together in the welding procedure. Current that is too low leaves an unfused sidewall; current that is too high increases heat input, distortion and base-metal melting.
Joint design also controls dilution: a deep groove that melts substantial parent metal can change the deposited chemistry. For a carbon-steel-to-stainless joint, ER309L provides alloy content intended to tolerate dilution from the carbon-steel side; ER308L can leave an unsuitable deposit.
ER312 is useful when dilution is high or hot-cracking resistance is important, but its hard, ferrite-containing deposit can complicate machining.
Keep heat input low enough for the required penetration and service limits. Excessive heat enlarges the fusion zone and raises dilution; too little heat leaves lack of fusion. Compare the selected filler against the actual joint design, welding position and current range, not base-metal thickness alone.
Turn the Selection into a Controlled Welding Specification
Before ordering, convert the choice into a traceable specification: base-metal grade and heat number, joint type, service temperature, environment, required properties, filler classification, diameter, and quantity. A rod that looks chemically suitable can fail after dilution, post-weld heat treatment, or exposure to chlorides, hydrogen, cryogenic temperatures, or galvanic contact.
1. Confirm the parent metal against the material certificate, heat-number marking, or PMI report. Record both sides of a dissimilar joint; do not assume a repair area has the same alloy as the surrounding plate.
2. Name the approved filler classification in the WPS, not only a trade name. For aluminium, document why ER5356 or ER4043 was selected: ER5356 offers higher deposited strength, while ER4043 gives fluid wetting and lower cracking risk in many 6xxx and cast-alloy joints. Check service temperature before approving ER5356.
3. For stainless steel and nickel alloys, verify ferrite control, corrosion conditions, and heat-treatment limits. Do not substitute ERNiCrMo-3 for ERNiCrMo-4, or the reverse, without the alloy manufacturer’s recommendation or a qualified procedure.
4. Specify rod diameter, surface condition, shielding gas, purge requirement, preheat, interpass temperature, current range, and cleaning method. Confirm the joint’s WPS or repair procedure covers the actual thickness and position.
5. Require the supplier’s classification, batch or heat number, certificate of conformity, and packaging condition. RND Welding Pvt Ltd can help you compare the supplied lot documents with the classification and diameter written in your WPS.
Reject rods with missing traceability, damaged packaging, contamination, or a classification that differs from the approved specification. Record the lot used on the weld report.
Related product
 | Welding Electrodes ₹ 2,800/KgGet Latest Price Wire Thickness 2 mm Grade Titanium-2 Brand Ador fontech Material Stainless Steel Color Silver Packaging Box Established in... View product → |
Frequently asked questions
Why must you identify the parent alloy before choosing a TIG filler rod?
Colour and surface appearance cannot reliably identify an alloy. Confirm the grade on each component and check its heat traceability, repairs, plating and mixed materials.
Should the filler chemistry match the base metal?
Use a matching filler when you need compatible chemistry and predictable properties. Choose a dissimilar filler when service conditions, crack resistance, corrosion performance or joining unlike alloys require it.
How do AWS classifications help you choose a TIG filler?
AWS classifications identify filler chemistry and intended applications. Compare the classification with the base alloy, service conditions and the requirements in your welding procedure.
How do dilution and joint design affect TIG filler selection?
Base-metal dilution changes the final weld chemistry. Joint thickness, gap, fit-up and access affect the filler volume and rod diameter you need.
What details belong in a controlled TIG welding specification?
Record the base-metal grades, filler AWS classification and diameter, shielding gas, joint design, polarity, current range, travel conditions, preheat or interpass limits and inspection requirements.
